C H A P T E R 7 T E S T S A N D T E S T C O N D I T I O N S
AT5600 User Manual 98-119 issue 14 Page 118
The primary and secondary voltages can be calculated from the following:
If you calculate V
s
or V
p
to be greater than 5V, you should set 5V as your test
signal. If you calculate V
s
or V
p
to be less than 1mV, you should set 1mV as your
test signal.
Table 5
Intermediate Inductance
(L
m
)
Preferred test signal
Frequency Voltage (V
m
)
100nH
1uH
10uH
100uH
1mH
10mH
100mH
1H
10H
100H
1KH
1uH
10uH
100uH
1mH
10mH
100mH
1H
10H
100H
1KH
10KH
300KHz
100KHz
30KHz
10KHz
1KHz
100Hz
100Hz
50Hz
50Hz
50Hz
20Hz
10mV
30mV
50mV
100mV
100mV
100mV
300mV
1V
5V
5V
5V
The Test Conditions for Turns Ratio by Inductance Measurement
Specifying the Test Limits
When specifying turns ratio tests, it is preferable to avoid limits which are
unnecessarily tight, and which may therefore lead to measurement difficulties.
For example, if two equal secondary windings should have 10 turns each, the
ratio should be 1:1. One turn in error would produce a ratio error of 10% or -10%
(i.e. 11:10 or 10:11), and therefore limits of +5% and -5% would be suitable to
detect the error.
Please also see
14.6.11 for specific advice on programming the test, and
10.2.5 for test accuracy specification
s
p
mp
N
N
VV =
p
s
ms
N
N
VV =
