C H A P T E R 1 3 – T E S T F I X T U R E S
AT5600 User Manual 98-119 issue 14 Page 259
13. Test Fixtures
Making connections to the AT5600
13.1. Introduction
This chapter is an introduction to the fixture system designed for use with the AT
series testers. Comprehensive instructions and application guidance for the
construction of your own custom fixtures, are supplied with every custom fixture
kit. The full fixture system user manual part number 98-028 is available from the
Voltech website.
The AT5600 can perform an extremely comprehensive series of tests on a wide
variety of wound components. To utilize this capability fully it is recommended that
test fixtures are constructed to suit each part to be tested.
Test fixtures are based on a fixture board containing connection pins. They
provide the interface to the tester via the tester node pins allowing transformers to
be quickly inserted and removed in a reliable manner taking full advantage of the
high-speed testing capability of the AT5600.
It is very important to use well-constructed test fixtures. These benefits include;
• minimizing operator fatigue
• ensuring optimum repeatability
• preventing unnecessary rejects
• increasing test throughput
Chapter
13
