C H A P T E R 10 – S P E C I F I C A T I O N S
AT5600 User Manual 98-119 issue 14 Page 240
10.2.32. DCVB Test
The accuracy of the test voltage is 3%.
The current measurement accuracy is based on the chosen test conditions, and is
given by:
where:
A
T
is the total accuracy (%)
A
R
is the basic relative accuracy (%)
A
C
is the calibration accuracy (%)
A
V
is the correction for voltage level (%)
A
I
is the correction for current level (%)
where:
where:
V
M
is the actual voltage (V)
I
M
is the maximum test current (A)
