C H A P T E R 10 – S P E C I F I C A T I O N S
AT5600 User Manual 98-119 issue 14 Page 211
10.2.3. QL and D Tests
The accuracy is based on the chosen test conditions, and is given by:
where:
A
T
is the total accuracy (%)
A
R
is the basic relative accuracy (%)
A
I
is the correction for current level (%)
A
QD
is the correction for Q or D factor (%)
where:
where:
I
M
is the measured current (A)
Q
M
is the measured Q factor
D
M
is the measured D factor
