Voltech AT5600 User Manual

C H A P T E R 1 1 – M A I N T E N A N C E
AT5600 User Manual 98-119 issue 14 Page 253
11. Maintenance
Before performing any maintenance on the AT5600, always disconnect the AC
line power supply cord and any peripherals.
11.1. Air Filters
The AT5600 houses two air filters that filter the air going through its cooling fans.
These filters will be cleaned during a service and calibration (if returned to a
Voltech service center), and if done annually, this is normally sufficient to maintain
the air flow through the instrument.
If the AT5600 is used in a particularly dusty environment, then the filters may
become clogged and cause the unit to get too hot. If this happens then a warning
message will be shown on the display and the filters will need cleaning.
To gain access to the filters, first remove the right-hand side panel as shown
below
11.1.1. Removing the right-hand side panel
Next unclip the filter retainers by pulling using fingers or a screw driver to release
the filters as shown
Chapter
11
