C H A P T E R 10 – S P E C I F I C A T I O N S
AT5600 User Manual 98-119 issue 14 Page 225
10.2.17. SURG Test
The measurement accuracy is based on the chosen test conditions, and is given
by:
where:
A
T
is the total accuracy (%)
A
R
is the basic relative accuracy (%)
A
C
is the calibration accuracy (%)
A
V
is the correction for voltage level (%)
where:
where:
V
P
is the programmed peak voltage (V)
Maximum programmable voltage
For UUTs with Ls => 125uH, the unit maximum is achievable, namely 5000V DC
For UUTs with Ls<=125uH, the maximum voltage achievable is defined by
Vout = (7000 * Luut) / (Luut + 50)
Where Luut = UUT Series Inductance in uH
