C H A P T E R 3 – U S I N G T H E A T 5 6 0 0
AT5600 User Manual 98-119 issue 14 Page 46
3.2. Test Fixtures
The AT Series has been designed with its own test fixture system to make
connections to a huge array of different component footprints.
1. Fixtures are constructed on a standard ‘fixture board’ which fits into the top
surface of the tester.
2. The fixture system uses Kelvin connections to give the best possible
measurements when testing wound components.
3. The fixture system will accommodate different types of connectors suitable for
both PCB mounting and flying lead transformers.
4. A single test fixture can be used for all transformers wound on the same
bobbin.
As well as the standard fixture system, custom fixtures are available from Voltech
partners. Please see the Voltech website www.voltech.com for more information.
For details of the Voltech fixture system, please see chapter 13, Test Fixtures.
