10.2.25. PHAS Test
The accuracy is based on the chosen test conditions, and is given by:
where:
A
T
is the total accuracy (°)
A
R
is the basic relative accuracy (°)
A
C
is the calibration accuracy (°)
A
V
is the correction for voltage level (°)
A
N
is the correction for turns ratio (°)
where:
where:
F
M
is the test frequency (Hz)
V
P
is the measured primary voltage (V)
TR
is the turns ratio between the primary and secondary
