C H A P T E R 1 3 – T E S T F I X T U R E S
AT5600 User Manual 98-119 issue 14 Page 265
13.5.1. Compensation Summary – Available Tests
TEST
COMPENSATION AVAILABLE?
Description
Mnemonic
S/C
O/C
Load
Continuity
CTY
Yes
No
No
DC Resistance
R
Yes
No
No
DC Resistance Match
R2
Yes
No
No
Inductance (Series circuit)
LS
Yes
Yes
No
Inductance (Parallel circuit)
LP
Yes
Yes
No
Inductance Match
L2
Yes
Yes
No
Inductance with Bias (Series)
LSB
Yes
Yes
No
Inductance with Bias (Parallel)
LPB
Yes
Yes
No
Impedance with Bias
ZB
Yes
Yes
No
Inductance with External Bias (Series)
LSBX
Yes
Yes
No
Inductance with External Bias (Parallel)
LPBX
Yes
Yes
No
Impedance with External Bias
ZBX
Yes
Yes
No
Quality Factor
QL
Yes
Yes
No
Dissipation Factor
D
Yes
Yes
No
Equivalent Series Resistance
RLS
Yes
Yes
No
Equivalent Parallel Resistance
RLP
Yes
Yes
No
Impedance
Z
Yes
Yes
No
Impedance Phase Angle
ANGL
Yes
Yes
No
Leakage Inductance
LL
Yes
Yes
Yes
Inter-winding Capacitance
C
Yes
Yes
No
Inter-winding Capacitance Match
C2
Yes
Yes
No
Turns Ratio and Phasing by Voltage
TR
No
Yes
No
Turns Ratio and Phasing by Inductance
TRL
Yes
Yes
No
Low open Circuit Voltage
LVOC
Yes
Yes
No
Inter-winding Phase
PHAS
Yes
Yes
No
Insertion Loss
ILOS
Yes
Yes
No
Return Loss
RLOS
Yes
Yes
No
Longitude Balance
LBAL
Yes
Yes
No
General Longitude Balance
GBAL
Yes
Yes
No
Frequency Response
RESP
Yes
Yes
No
Magnetizing Current
MAGI
No
Yes
No
Open Circuit Voltage
VOC
No
Yes
No
Wattage
WATT
No
Yes
No
Stress Wattage
STRW
No
Yes
No
Magnetizing Current (External Source)
MAGX
No
No
No
Open Circuit Voltage (External Source)
VOCX
No
No
No
Wattage (External Source)
WATX
No
No
No
Stress Wattage (External Source)
STRX
No
No
No
Leakage Current
ILK
No
Yes
No
Insulation Resistance
IR
No
Yes
No
Hi-Pot (DC)
HPDC
No
Yes
No
Hi-Pot (AC)
HPAC
No
Yes
No
Hi-Pot Ramp (DC)
DCRT
No
Yes
No
Hi-Pot Ramp (AC)
ACRT
No
Yes
No
Voltage Break down (DC)
DCVB
No
Yes
No
Voltage Break down (AC)
ACVB
No
Yes
No
Surge Stress
SURG
No
No
Yes
Output to User Port
OUT
No
No
No
