C H A P T E R 10 S P E C I F I C A T I O N S
AT5600 User Manual 98-119 issue 14 Page 244
10.3.4. Peripheral Interface
This interface is for connection only to an approved Voltech accessory.
Do not try to make other connections to this interface as damage may occur.
15-pin female D-type connector
Pin
Signal name
Pin
Signal name
1
o/p
CC
9
o/p
LP_HI
2
o/p
LP_LO
10
No connection
3
o/p
+12V
11
i/p
AUXTRIP\
4
o/p
ENAUX
12
No connection
5
o/p
AUX_RELAY
13
0V(AUX)
6
0V(HP)
14
o/p
HP_OUT
7
No connection
15
No connection
8
i/p
AUX_IN
HP_OUT Pin 14
DANGEROUS voltage up to 400V can be present on the HP_OUT pin when any
attached safety device signals a safe condition.
General Signal Pins
Except for the HP_OUT pin, the other signals are either digital TTL type outputs
or inputs, or connections through to the internal power supplies and signal
generator sources.
