C H A P T E R 10 – S P E C I F I C A T I O N S
AT5600 User Manual 98-119 issue 14 Page 214
10.2.6. MAGI Test
The accuracy of the applied test voltage is 1%.
The measurement accuracy of MAGI is based on the chosen test conditions, and
is given by:
where:
A
T
is the total accuracy (%)
A
R
is the basic relative accuracy (%)
A
C
is the calibration accuracy (%)
A
I
is the correction for current level (%)
where:
where:
F
M
is the test frequency (Hz)
I
M
is the measured current (A)
