C H A P T E R 10 – S P E C I F I C A T I O N S
AT5600 User Manual 98-119 issue 14 Page 226
10.2.18. L2, C2 and R2 Tests
The accuracy is dependent on the accuracy of the two inductance, capacitance or
resistance measurements made, and is given by:
where:
A
T
is the total accuracy (%)
A
X
is the accuracy of the X measurement (%)
A
Y
is the accuracy of the Y measurement (%)
Refer to the accuracy specifications for the LS, C and R tests to determine the
accuracy of the X and Y measurements (10.2.2 and 10.2.1).
