C H A P T E R 2 – S Y S T E M O V E R V I E W
AT5600 User Manual 98-119 issue 14 Page 42
2.7. Tilt Feet
To improve the visibility of test pins under certain operator seating arrangements,
or to give the AT5600 the same tilt as the AT3600, the rear feet may be tilted.
Tilting the feet
2.8. Lifting Points
Two lifting points (one for each hand) are provided beneath each side vent.
Always remove any fixture and other accessories fitted before lifting.
Lifting should be done from the rear (to minimize the distance from the body) with
the fingers of each hand placed inside the recesses.
Always follow good manual handling practices. If you are unsure of how to safely
lift this product, then please consult your health and safety information.
For handling, the weight of this product should be taken as 19 Kg.
See section 10.5 for full weight and dimension information.
