C H A P T E R 10 – S P E C I F I C A T I O N S
AT5600 User Manual 98-119 issue 14 Page 209
10.2. Accuracy Specifications – Available Tests
10.2.1. R Test
The accuracy is based on the chosen test conditions, and is given by:
where:
A
T
is the total accuracy (%)
A
R
is the basic relative accuracy (%)
A
C
is the calibration accuracy (%)
A
V
is the correction for voltage level (%)
A
I
is the correction for current level (%)
where:
where:
V
M
is the measured voltage (V)
I
M
is the measured current (A)
The test signal is set according to the value specified as maximum in the test
limits: -
Where:
V = Volts (V)
I = Current (A)
R = Resistance (Ω)
