C H A P T E R 10 – S P E C I F I C A T I O N S
AT5600 User Manual 98-119 issue 14 Page 208
Notes:
1 A
R
= the basic relative accuracy (see later for the full specification).
2 Depends on external source type.
3 650 Vrms for AC measurements, or 900 V for DC measurements.
Note: 25W MAX for VOC/MAGI/WATT/STRW.
4 Peak value
5 DC bias current accuracy is +/-10% of the requested value.
Test Frequency Accuracy
F <= 16 kHz error is +/-0.25Hz +/- 0.01% of requested frequency.
F >16 kHz and <= 250kHz error is +/- 4Hz +/- 0.01% of requested frequency.
F > 250 kHz error is +/- 64 Hz +/- 0.01% of requested frequency.
Signal Level Accuracy
Voltage +/- 1mV +/- (2.5% +/- 0.01% / kHz) of test signal.
Current: +/- 100 uA +/- (2.5% +/- 0.01% / kHz) of test signal.
Tests in BOLD
MAGX VOCX WATX STRX - for use with AC INTERFACE.
LSBX LPBX ZBX - for use with DC1000 / DC1000A.
