C H A P T E R 1 4 - A T E D I T OR
AT5600 User Manual 98-119 issue 14 Page 275
You may move the cursor focus between the fill-in boxes by using the TAB key or
by pointing to the fill in box and clicking with the mouse.
When both terminals have been named, you should press ENTER on the
keyboard or click on OK with the mouse in the dialogue box.
To make a winding with more than two terminals, see “
Adding a Terminal to an Existing Winding” in section 14.4.5.
NOTE: Terminal names may be between 1 and 6 characters in length and
may contain any upper-case letter or AT Series keyboard character excluding
SPACE.
