C H A P T E R 2 – S Y S T E M O V E R V I E W
AT5600 User Manual 98-119 issue 14 Page 40
(9) Server Port
This RS232 serial port if used for connection to a computer system running the
Voltech AT Series Server software. It is normally only used for legacy connections
where an AT5600 is being used to replace an AT3600 or ATi.
(10) Power Switch and Disconnection Device
Switches the unit on and off by breaking the mains power to the unit. No power is
drawn from the supply when switched off. Connect the power outlet to this socket
using the supplied power cord or equivalent to IEC60320 C13 type with 3A
minimum current capability and voltage rating greater or equal to the mains
supply voltage. Contained within the module are two fuses which must always be
replaced when necessary with the same type and rating (2.0AT 5X20
ANTISURGE).
