Voltech AT5600 User Manual

C H A P T E R 1 6 - C H A N G E L O G
AT5600 User Manual 98-119 issue 14 Page 403
Table:
tblVoltechResults
Field
Format
Notes
ResultID
Text (25)
Index ID
RunID
Text (25)
As tblVoltechRunID.RunID
TestID
Text (25)
As tblVoltechTestID.TestID
TestNo
Number
(Long Integer)
Test number as in test program
OC_Comp
Text (5)
YES, NO, N/A
Open Circuit Compensation status
SC_Comp
Text (5)
YES, NO, N/A
Short Circuit Compensation status
Load_Comp
Text (5)
YES, NO, N/A
Load Compensation (future
development)
Result
Number (Single)
Actual test result
TestStatus
Text (5)
DSP Status for test
PassFail
Text (5)
PASS/FAIL
Individual test pass or fail result
Table:
tblVoltechTestID
Field
Format
Notes
TestID
Text (25)
Index ID
TestMnemonic
Text (10)
Individual test mnemonic
TestUnits
Text (10)
Individual test units
CheckType
Text (5)
NONE/MIN/MAX/DIFF/POL
Type of test limits (see *)
MinLimit
Number (Single)
Minimum limit for test (see *)
MaxLimit
Number (Single)
Maximum limit for test (see *)
* Notes:
(CheckType = NONE) If there are no Min or Max limits,
MinLimit = 0 and MaxLimit = 0
(CheckType = MIN) If there is a Min limit only, MaxLimit = 0
(CheckType = MAX) If there is a Max limit only, MinLimit = 0
(CheckType = DIFF) If there is a Min and Max limit
(CheckType = POL) Polarity test
If Positive Polarity test, MinLimit = 0 and MaxLimit = 1
If Negative Polarity test, MinLimit = -1 and MaxLimit = 0
