Xerox Phaser 6100 Service Manual

Disassembly
Service Manual 6-49
6.4.24 Temperature Sensor (PL 9.16.23)
1. Remove the Front Cover and Top Cover. (6.4.1)
2. Remove the Rear Cover. (6.4.3)
3. Remove the Duplex Cover. (6.4.4)
4. Remove the LVPS and LVPS Cover. (6.4.7a)
5. Remove the Main Board Shield. (Steps 1 and 2 of 6.4.11)
6. Remove the DEVE Cover (Door A). (6.4.15)
7. Remove the Laser Cover. (6.4.15.1)
8. Remove the DEVE Drive Assembly. (6.4.11)
9. Remove the Erase Lamp. (6.4.14)
10. Remove the Waste Toner Auger Assembly. (6.4.18)
11. Remove the Main Drive.
12. Remove all 7 base screws, 1 (3-8 black) and 6 (4-10 silver) and gently lift the rear, right of the frame enough to
feed the harness between the base and the frame.
13. Remove 3 screws securing the DEVE covers rear hinge bracket to the base.
14. Remove the sensor.

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
