Xerox Phaser 6100 Service Manual

Maintenance and Diagnostics
Service Manual 7-1
This chapter describes some of the main service procedures including:
■ Using the Engine Diagnostic Contol mode (EDC)
■ Clearing paper jams
■ Test patterns.
Much of this chapter is also included in the user’s guide.
7.1 Paper path and Paper jam
7.1.1 Paper path
7
Maintenance and
Diagnostics
DEV. - Black
DEV. - Yellow
Pick-up
Roller
DEV. - Magenta
DEV. - Cyan
CASSETTE
Feeder
DUPLEX
Fuser Unit
EXIT Ass'y
MPF Path
Duplex Path
Duplex Path
MPF
MPT
DEV. - Black
DEV. - Yellow
Imaging
Unit
Imaging
Unit
DEV. - Magenta
DEV. - Cyan
SCF
Tray 2
Tray 1
Transfer
Belt
Transfer
Belt
Feeder
DUPLEX
Fuser Unit
EXIT Unit
SCF Path
Transfer Roller
Exit Sensor
Paper Pick-Up Roller
Paper Empty Sensor(FCT)
Paper Empty Sensor(SCT)
Paper Empty
Sensor(MPT)
Feed Sensor
Path
Path
MPT Path

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
