Xerox Phaser 6100 Service Manual

Maintenance and Diagnostics
7-14
7.6.2.2 Solenoid Tests
This function allows the operation of the various solenoids and clutches to be checked.
<How to operate>
a. Press the Scroll button until “Solenoid” is displayed.
b. Press the OK button to select this function.
c. Press the Scroll button until you see the name of the solenoid or clutch you wish to test.
d. Press the OK button to run the test. The test is stopped by pressing the Back button.
e. Pressing the Back button when the test is already stopped will return to Step ‘C’ above.
f. Pressing the Back button again will return to the EDC main menu.
Menu Item Description Test Results
Y Clutch
Operates the yellow developer clutch. On or Off
M Clutch
Operates the magenta developer clutch. On or Off
C Clutch
Operates the cyan developer clutch. On or Off
K Clutch
Operates the black developer clutch. On or Off
Y Solenoid
Operates the yellow developer solenoid. On or off
M Solenoid
Operates the magenta developer solenoid. On or Off
C Solenoid
Operates the cyan developer solenoid. On or Off
K Solenoid
Operates the black developer solenoid. On or Off
Feed Clutch
Operates the feed clutch. On or Off
T2 Clutch
(Transfer Roller)
Operates the transfer roller T2 solenoid. On or Off
ITB Clutch
(Transfer Belt)
Operates the transfer belt cleaning solenoid. On or Off
Duplex Solenoid
Operates the duplex solenoid. On or Off
Tray 1 Clutch
Operates the Tray 1 clutch. On or Off
MPT Clutch
Operates the MPT clutch. On or Off
Tray 2 Clutch
(if installed)
Operates the Tray 2 clutch, if the optional
500-sheet feeder is installed.
On or Off

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
