Xerox Phaser 6100 Service Manual

Troubleshooting
Service Manual 8-3
8.1.2 Initial Inspection
1. Check printer power.
a. The printer does not work at power on.
Is the power switch (printer and wall socket) turned on?
Is the power cord connected to the printer correctly?
Is the power cord connected to the wall socket correctly?
Is the wall socket outputting the correct voltage?
Is the printer rated as the same voltage as the supply?
b. The fan doesn’t work when power is turned on?
Check the connectors on the LVPS.
Check the fuses in the LVPS.
Check any error message displayed on the control panel and refer to the troubleshooting Section 8.4 or 8.5.
2. Check the printer environment.
a. Ensure the surface the printer is on is flat, level and free from vibration.
If necessary, move the printer.
b. Ensure that the temperature and humidity of the surrounding area are within specification.
If necessary, move the printer.
c. Ensure that the printer is positioned away from any air conditioning or other heating or cooling equipment.
Also ensure that it is not positioned in a direct draft from any air conditioning, fan or open window.
If necessary, move the printer.
d. Ensure the printer is not positioned in direct sunlight.
If it is unavoidable, use a curtain to shade the printer.
e. Ensure the printer is installed in a clean, dust free environment.
Move the printer to a clean area if necessary.
f. Some industrial or cleaning processes give off fumes which can affect the printer.
Move the printer away from this type of air pollution
3. Check the paper type.
a. Use only media that is of an approved quality, type, weight and size?
See Section 3 of this manual.
4. Check the overall condition of the printer.
a. Is the printer properly maintained?
Ensure the paper path is clean and free from debris.
Rollers with excessive wear or dirty surfaces should be cleaned or replaced.

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
