Xerox Phaser 6100 Service Manual

Block Diagram
Service Manual 10-1
10. Block Diagram
10
Block Diagram
Control
Panel
16x2 LCD
16bit
Ethernet
(DN Only)
32bit
LSU
8~16bit
HVPS
PWM control
*For Engineering
Use Only
Analog MUX
- TEMP.(2 EA) - Fusing Temp. -HVPSx3 -CTD - OPC key - Waste Toner - Waste Auger * Total : 10 input
5pin, UART
UART
32bit
16bit
60MHz
Parallel Port
USB 2.0
Flash Memory
2MB
SDRAM
64MB +
Option Memory
Motors
SPGPm
EEPROM
LPEC1
Color ASIC

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
