Xerox Phaser 6100 Service Manual

Maintenance and Diagnostics
7-12
7.6.2 EDC Menu Map
MOTOR TEST
Main Motor
Dev Motor
Fan Motor
Waste Motor
Tray 2 Motor
TEST PRINT
Select Tray
Select Pattern
Color Bar 4x4
Solid
Print Pattern
HVPS PRINT
Charger
T1
T2
Dev DC
Dev AC
REGI. SET
Yellow (+ / - 5)
Magenta (+ / - 5)
Cyan (+ / - 5)
Black (+ / - 5)
MAINTENANCE
New Developer Cluch
MPT Pick-up
Tray 1 Pick-up
Tray 2 Pick-up*
Transfer Roller
LSU & FUSER TEST
LSU Test
Laser Diode
Fuser
SOLENOID TEST
Y Clutch
M Clutch
C Clutch
K Clutch
Y Solenoid
M Solenoid
C Solenoid
K Solenoid
Feed Clutch
T2 Clutch
(Transfer Roller)
ITB Clutch
(Transfer Belt)
Duplex Solenoid
Tray 1 Clutch
MPT Clutch
Tray 2 Clutch*
SENSOR TEST
Feed Sensor
Exit Sensor
Waste Box Sensor
Side Cover
Tray 1 Empty Sensor
MPT Sensor
Tray 2 Empty Sensor*
Tray 2 Cover Sensor*
* If optional Tray 2-500 Sheet Feeder (SCF Cassette) is installed

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
