Xerox Phaser 6100 Service Manual

System Outline
Service Manual 5-11
6) Motor Torque Check
7) Check and Set a High Voltage Condition (T1, T2, Charger)
8) Initialize Printing Parameters
■ Paper size, copies, trays
■ Image pixels, image times, y-offset, x-offset
■ Sensors
■ Color print mode:
■ Except legal & OHP/Legal/OHP
■ Simplex/Duplex
■ Mono print mode: Simplex/Duplex/OHP
5.2.5 Print
After sensing the transfer belt home position the following tasks are performed:
■ Send Psync signal to controller
■ Operates virtual timer for each color(Vdata)
■ Forms latent image on drum
■ Supplies toner on OPC drum
■ Transfers image to transfer belt (T1 )
■ Picks paper
■ Transfers image to paper (T2)
1) Check Transfer Belt Home (Treated by Home interrupt every 3 seconds):
a. Transfer belt home sensing
b. If test mode is selected, a test pattern is printed.
c. A counter value is set up that addresses the timing to turn on page sync.
d. The virtual timer for each color (Y, M, C, and K) is set up.
e. If home is not detected every 3 seconds, an error is reported on the control panel.
2) Paper Path Printing
a. Paper is picked from Tray 1, Tray 2, or MPT
b. Control paper path
■ Paper pick stops when the leading edge of the paper reaches the feed sensor.
■ If the leading edge doesn’t reach the feed sensor, an error is reported.
■ While transferring the last color to the transfer belt, transports the paper.
■ Checks if the paper reaches the exit sensor in the specified amount of time, otherwise an error is reported.
■ Checks paper passing the exit sensor.
c. Jam check
■ Check paper reaching and passing the feed and exit sensors, otherwise an error is reported.
d. Duplex control
■ After passing the exit sensor, the duplex clutch is engaged to mechanically change the direction of the
paper in order to print the other side.
e. Printing sequence for each color
■ Uses a virtual timer for printing the colors in the correct sequence. (Yellow, Magenta, Cyan, Black)
A virtual timer is an algorithm for creating regular action at fixed time intervals. The standard setting is for a
5 msc timer interrupt.

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
