Xerox Phaser 6100 Service Manual

Maintenance and Diagnostics
Service Manual 7-13
7.6.2.1 Motor Tests
This function allows the operation of the various motors to be checked.
<How to operate>
a. Press the Scroll button until “Motor Test” is displayed.
b. Press the OK button to select this function.
c. Press the Scroll button until you see the name of the motor you wish to test.
d. Press the OK button to run the test. The test is stopped by pressing the Back button.
e. Pressing the Back button when the test is already stopped will return to Step ‘C’ above.
f. Pressing the Back button again will return to the EDC main menu.
Menu Item Description Test Results
Main Motor
Operates main motor. Success or Failed
Dev Motor
Operates the developer motor. Success or Failed
Fan Motor
Operates the fan motor. On or Off
Waste Motor
Operates waste motor On or Off
Tray 2 Motor
Operates the Tray 2 motor (if installed) On or off

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
