Xerox Phaser 6100 Service Manual

Reference Information
2-2
2.2 Acronyms and Abbreviations
Definition Definition
ADC Analog-to-digital Conversion F/W Firmware
AP Access Point FCF/FCT Tray 1 or First Cassette Feeder
AC Alternating Current FISO Front In, Side Out
ASIC Circuit Application Specific Integrated FPOT First Print Out Time
Ass’y Assembly GDI Windows Graphic Device Interface
BIOS Basic Input Output Sytem GIF Graphic Interchange Format
BLDC Motor Brushless Dc Motor GND Ground
CMOS Complementary Metal Oxide
Semiconductor
HBP Host Based Printing
CMYK Cyan, Magenta, Yellow, Black HDD Hard Disk Drive
CN Connector HTML Hyper-text Transfer Protocol
CON Connector HV High Voltage
CPU Central Processing Unit HVPS High Voltage Power Supply
CTD Sensor Color Toner Density Sensor I/F Interface
dB Decibal I/O Input/output
dBA A Weighted Decibel lb Pound(S)
dBm Decibel Milliwatt IC Integrated Circuit
DC Direct Current ICC International Color Consortium
DCU Diagnostic Control Unit IDE Intelligent/integrated Drive Electronics
DIMM Dual In-line Memory Module IEEE Institute Of Electrical And Electronics
Engineers, Inc.
DPI Pots Per Inch IOT Image Output Terminal (Color Printer,
Copier)
DRAM Dynamic Random Access Memory IPA Isopropyl Alcohol
DVM Digital Voltmeter IPC Inter Process Communication
ECP Enhanced Capability Port IPM Images Per Minute
ECU Engine Control Unit ITB Image Transfer Belt (Transfer Belt)
EEPROM Electronically Erasable
Programmable Read Only Memeory
LAN Local Area Network
EMI Electro Magnetic Interference LBP Laser Beam Printer
EP Electro Photographic LCD Liquid Crystal Display
EPP Enhanced Parallel Port LED Light Emitting Diode
LSU Laser Scanning Unit

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
