Xerox Phaser 6100 Service Manual

Reference Information
Service Manual 2-3
LVPS Low Voltage Power Supply Or SMPS
MB Megabyte Q’ty Quantity
MHz Megahertz RAM Random Access Memory
MPBF Mean Prints Between Failure ROM Read Only Memory
MPF/MPT Multi-purpose Tray SCF/SCT Tray 2 Or Second Cassette Feeder
NIC Network Interface Card SMPS Switching Mode Power Supply or LVPS
NPC Network Printer Card SPGPm Samsung Printer Graphic Processor
NVRAM Non-volitale Random Access Memory SPL Samsung Printer Language
OPC Organic Photo Conductor Spool Simultaneous Peripheral Operation Online
PBA Print Board Assembly SW Switch
PCI Peripheral Component Interconnect SURF Surface Rapid Fusing
PCL Printer Command Language Sync Synchronous
PDF Portable Document Format T1 ITB or Transfer Belt Imaging
PDL Page Description Language T2 Transfer Roller Imaging
Ping Packet Internet Or Inter-network
Grouper
TRC Toner Reproductive Curve
PPD Postscript Printer Description PnP Universal Plug-n-play
PPM Pages Per Minute URL Uniform Resource Locator
PS Postscript USB Universal Serial Bus
PTL Pre-transfer (Erase) Lamp
PWM Pulse Width Moduration
Definition Definition

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
