Xerox Phaser 6100 Service Manual

Parts List
Service Manual 9-1
Contents
■ 9.0 Consumables, Routine Maintenance Items and Options
■ 9.1 Main Exploded View
■ 9.2 Front Cover
■ 9.3 Top Cover
■ 9.4 DEVE Cover (Door A)
■ 9.5 Exit Assembly
■ 9.6 Duplex Assembly
■ 9.7 DEVE Drive Assembly
■ 9.8 Main Drive Assembly
■ 9.9 Fuser Assembly
■ 9.10 Paper Tray, Tray 1 (FCT)
■ 9.11 Paper Tray, Tray 2 (SCT)
■ 9.12 Optional 500-Sheet Feeder (SCF)
■ 9.13 Main Frame
■ 9.14 Front Frame Assembly
■ 9.15 Rear Frame Assembly
■ 9.16 Base Frame Assembly
■ 9.17 MPT Assembly
■ 9.18 Pickup Assembly
■ 9.19 Feeder Assembly
■ 9.20 Paper Guide Assembly
■ 9.21 Transfer Belt Cam Assembly
■ 9.22 Fuser Base Assembly
■ 9.23 Xerox Kits and Accessories
9
Parts List

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
