Xerox Phaser 6100 Service Manual

Maintenance and Diagnostics
7-16
7.6.2.5 Test Prints
This function allows the printer to be checked by printing various test prints.
<How to operate>
a. Press the Scroll button until “Test Print” is displayed.
b. Press the OK button to select this function.
c. Press the Scroll button until you see “Select Tray” is displayed.
d. Press the OK button.
e. Press the Scroll button select a tray.
f. Press the OK button.
g. Press the Scroll button until you see “Select Pattern” is displayed.
h. Press the OK button.
i. Press the Scroll button to select the pattern (either or .
j. Press the OK button.
k. Press the Scroll button until you see “Print Pattern” is displayed.
l. Press the OK button to print.
m. Pressing the Back button twice will return to the EDC main menu
n. In testing the Laser (LSU) motor the laser lock time is variable between 6 and 15 seconds, depending on the
environment.

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
