Xerox Phaser 6100 Service Manual

Maintenance and Diagnostics
Service Manual 7-19
7.6.2.8 Color Calibration
This feature controls the setting of the TRC (Tone Reproduction Curve).
Note
Color Calibration can be found on the control panel’s main menu, in normal customer mode, and is not part of
the EDC diagnostic tests.
<How to operate>
a. From the main menu, in customer mode, go to “Color”, then “Calibration”.
b. Press the OK button to select this function.
c. Use the Scroll button to move through the menu items.
■ Off turns TRC off
■ Auto is the default setting
■ Run Now will perform (on the next print) a color measurement and adjust according to the TRC.
d. Press the OK button to select this function.
e. From the main menu, in customer mode, go to “Color”, then “Custom Color”.
f. Press the OK button to select this function.
g. Press OK again to select CMYK.
h. Use the Scroll button to select “Default” or “Manual Adjust”.
■ Manual Adjust allows for a manual adjustment of each color.
Note
For more details on the TRC process refer to section 5.1.4.4 in section 5 of this manual.

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
