Specifications
3-2
3.2 Controller Specification
3.3 Electrical Specification
Item Description
Processor SPGPM (Samsung Printer Graphic Processor) Clock speed 120 MHz
Memory The controller has 64 MB SDRAM and 4 MB flash ROM on Board.
1 DIMM expansion slot for SDRAM DIMM Package: DIMM; 100-pin
Type: SDRAM
DIMM Type: Unbuffered (SEC Custom, support other products within SEC)
Error Checking: Non-parity
Speed: 120/133 MHz
Voltage: 3.3 V
Samsung proprietary design 64/128MB
(128 MB Not currently supported)
Emulation SPL-Color
Operating Systems Win 95/98/Me/NT/2000/XP, Mac OS 9 USB only, Linux
Interface One parallel port
IEEE 1284 -1994 compliant, (Bi-directional, ECP/Nibble/Byte Mode)
One USB port
USB v.2.0 compliant
Color-coded to meet WHQL requirements, connector must be Pantone 426C
One 10/100 BaseT NIC connector
- The printer supports an internal Network Interface Card (NIC), which can be
installed pre-configured at the factory. This NIC supports all of the major
Network Operating Systems, such as the Novell NetWare, TCP/IP, etc.
Interface switching Automatic
Interface time-out 5 min (max.)
Font Windows Font
Color Management ICC ICM V3.4
Item Description
Input Voltage Low voltage: 100-127 VAC High voltage: 220-240 VAC
Input Range 90-135 VAC 180-264 VAC
Nominal Frequency: +/- 47/63 Hz +/- 47/63 Hz
Frequency tolerance +3 Hz +3 Hz
Power Consumption Print mode: 450 watts or less
Standby mode: 160 watts
Sleep mode: 35 watts
