Xerox Phaser 6100 Service Manual

Disassembly
Service Manual 6-45
6.4.20 Main Frame (PL 9.13) and Base Frame (PL 9.16)
1. Remove the Front Cover and Top Cover. (6.4.1)
2. Remove the Rear Cover. (6.4.3)
3. Remove the Duplex Cover. (6.4.4)
4. Remove the LVPS and LVPS Cover. (6.4.7a)
5. Remove the Main Board Shield. (Steps 1 and 2 of 6.4.11)
6. Remove the DEVE Cover (Door A). (6.4.15)
7. Remove the Laser Cover. (6.4.15.1)
8. Remove the DEVE Drive Assembly. (6.4.11)
9. Remove the Erase Lamp. (6.4.14)
10. Remove the Waste Toner Auger Assembly. (6.4.18)
11. Remove the Main Drive.
12. At the end of the erase lamp, remove the 1 black screw (3-8) from the grounding strap.
13. Disconnect all wiring harnesses from the lower portion of the chassis.
14. Cut the two tie wraps securing the harnesses together.
Caution
Be sure the harnesses are all routed out of the way so that on reassembly the harnesses do not
get damaged. Use care to protect the harnesses and erase lamp from damage.
15. Lift the main frame of the chassis off the base frame.
>> On re-assembly:
Note
There are 2 extra untapped holes on the front and back of the base that can be used if the others
become damaged.

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
