Xerox Phaser 6100

Parts List
Service Manual 9-29
9.14 Front Frame Assembly
Front Frame Assembly 9.14
No. Part number Qty Part Name and (part description)
0 1Frame Front
1 116-1879-00 1 Waste Toner Sensor
1-1 P/O Hardware Kit 1 Ring CS
1-2 1 Holder M Waste Toner Sensor
