Xerox Phaser 6100 Service Manual

Parts List
9-30
1-3 116-1881-00 1 Waste Toner Sensor Actuator
1-4 1 Sub Waste Sensor
2 1 Transfer Belt Lifter
2-1 1 Sponge Duct Toner Transfer Belt Lift
2-2 1 Duct Toner Transfer Belt Lifter
2-3 1 Sponge Transfer Belt Duct
3 116-1883-00 1 Transfer Belt Waste Toner Housing
3-1 1 Housing M Waste Toner Transfer Belt
3-2 1 Sponge Duct Toner OPC
3-3 1 Cap Shutter Transfer Belt
3-4 1 Shutter Transfer Belt
3-5 1 Sponge Transfer Belt Tank Dust
3-6 1 Sponge Transfer Belt Tank Toner
3-7 1 Sponge Cap Shutter
3-S8 1 Screw-Taptite
4 P/O Hardware Kit 3 Ring CS
5 116-1875-00 1 Exit Sensor
6 1 Plate Guide T2 Front
7 1 Bracket Laser F
8 116-1885-00 12 Terminals
9 1 Ground HVPS Laser
10 1 Link Lock OPC F
11 1 Lever Transfer Belt Lock Front
12 1 Label(R) Color Bar
13 1 Harness Bushing Ground
14 1 Bracket Guide HVPS R
15 1 Bracket Exit Hinge F
16 1 Transfer Belt Hinge Ground
17 1 Transfer Belt Guide Tortion
18 1 OPC Guide Tortion
19 1 OPC/Transfer Belt Bround
20 1 OPC Lock Front
21 1 OPC/Laser Ground
22 1 Shutter Tortion
23 1Frame Front
24 1 Cover Top Lever In
25 1 Cover Top Lever Out
26 1 DEVE Open Plate
27 1 DEVE Open Plate Guide
28 116-1921-00 1 Spring CS (Belt)
29 1 Lock Transfer Belt Front
30 1 Lock Cover Front
31 1 Rack OPC
32 2 Spring CS
33 1 Guide Lock OPE F
34 1 Sponge Dust Transfer Belt Cover
35 1 Sponge Dust Imaging Unit Cover
36 116-1922-00 1 DEVE OEM Board
37 116-1923-00 2 Spring CS (Frame)
No. Part number Qty Part Name and (part description)

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
