Xerox Phaser 6100 Service Manual

Parts List
9-28
9 1Frame Base
10 1 Frame Rear
11 1Frame Front
12 116-1874-00 1 Erase Lamp
13 1 ShutterTension
14 P/O Hardware Kit 4 Ring CS
15 1 Cable Clamp
16 116-1919-00 1 Dust Cover OPC
17 116-1920-00 1 OPC Toner Housing
17-1 1 Vibration Plate Outlet
17-2 1 Bushing Waste Cam M
17-3 1 Cap Shutter Transfer Belt
17-4 1 Housing Transfer
17-5 1 Shutter Transfer OPC
17-6 1 Sponge Toner Cartridge
17-7 1 Sponge Cap Shutter
17-8 1 Sponge Duct Toner OPC
17-9 1 Sponge Tank Toner OPC
17-S5 P/O Screw Kit 2 Screw-Taptite
17-S8 P/O Screw Kit 1 Screw-Taptite
18 2 Spring Clutch
19 116-1949-00 1 CBF Harness Waste Motor
20 116-1866-00 1 SUB DEVE Drive Board
21 1 Harness Main FSR Roll
22 116-1941-00 1 CBF Harness Main Eraser
23 1 Ground Fuser Frame
24 1 Sheet Eraser Lamp
25 1 Gear Fuser DRV Outer
26 1Gear-DP Idle
27 2Gear Exit Idle Z17
28 1 Ground Paper Guide
29 1Cover Fuser Base
30 1 Cover Harness Fuser
31 1 Laser Shutter Cover
32 116-1885-00 4 Terminals
33 1 Washer Plain
S5 P/O Screw Kit 8 Screw-Taptite
S6 P/O Screw Kit 1 Screw-Taptite
S7 P/O Screw Kit 2 Screw-Taptite
S8 P/O Screw Kit 29 Screw-Taptite
S9 P/O Screw Kit 2 Screw-Taptite
S14 P/O Screw Kit 7 Screw-Taptite
No. Part number Qty Part Name and (part description)

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
