Parts List

Service Manual 9-27

Main Frame 9.13

No. Part number Qty Part Name and (part description)

1 116-1872-00 1 OPC Waste Toner Duct

1-1 116-1956-00 1 Waste Toner Motor ASM

1-1-S1 2 Screw-Machine

1-1-1 116-1957-00 1 E-ring (also in hardware kit)

1-1-2 116-1958-00 1 Waste Toner Motor-DC

1-1-3 1 Bracket Waste Toner Motor

1-1-4 1 Gear Worm Wheel Idle

1-1-5 1 Gear Worm Waste Toner

1-2 1 Harness Toner Ground

1-3 2 Bushing D6/L4

1-4 1 Vibrator Inlet Plate

1-5 1 Base M Waster Toner

1-6 1 Pipe Waste Bar

1-7 1 Cam M Waste Duct Outlet

1-8 1 Gear Worm Wheel Z35

1-9 1 Shaft M Waste Duct Inlet

1-10 1 Duct M Waste Lifter

1-11 1 Duct M Waste Toner Inlet 1

1-12 1 Duct M Waste Toner Inlet 2

1-13 1 Pipe Waste Transfer

1-14 1 Sponge Waste Lifter 1

1-15 1 Sponge Waste Lifter 2

1-16 1 Sponge Waste Duct OPC

1-17 1 Sponge Waste Cover

1-18 116-1957-00 1 E-Ring (also in hardware kit)

1-19 1Spring CS

1-20 2Spring CS

1-S8 6Screw Taptite

2 1 Holder Eraser

3 1 LSU Guide Bracket

3-1 1 Bracket LSU

3-2 1 LSU Base

3-3 1 Ground LSU

3-4 2 IPR Plate OPC OEM

3-5 116-1885-00 2 Unit Terminals

3-6 1 Cover OEM Upper

3-7 116-1950-00 1 Harness Main OPC_OEM

3-S5 P/O Screw Kit 2 Screw-Taptite

3-S9 P/O Screw Kit 5 Screw-Taptite

4 1 Sheet HV Harness

5 1 Bracket HVPS

5-1 3 Guide HVPS Board

5-2 1 Bracket HVPS Lower

5-3 2 Cable Clamp

6 1 Guide paper T2

7 1Fuser Base

8 116-1873-00 1 ITB Cam ASM (Transfer Belt Cam)
