Xerox Phaser 6100 Service Manual

Troubleshooting
8-24
Install [Color] Toner
Occurs when the toner cartridge of the indicated
color is not installed.
If the toner cartridge is not installed.
The resistor cannot be read due to the
contamination of the contact points.
1. Verify the toner cartridge is installed.
2. Check the contact point for contamination.
3. Replace the toner cartridge.
4. Replace the DEVE_OEM board, the HVPS or the main
board.
Tray 2 Error
Tray 2 is not installed properly. 1. Turn off the printer and re-insert Tray 2.
Cover D Open
Tray 2 cover is open. 1. Open and close the Tray 2 cover properly.
2. If the fault continues, refer to section 8.3.6 for additional
troubleshooting.
Waste Cartridge Full/Not Installed
Waste toner cartridge is full or not installed. 1. Check the waste toner cartridge for proper installation.
2. If it is full, replace the waste toner cartridge.
3. Check the waste toner sensor and actuator for damage or
defects. Replace if defective.
4. Check the waste toner sensor, cable harness. Re-seat or
replace if defective.
5. Replace the main board.

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
