Parts List
Service Manual 9-11
9 1 Cover Exit R Cap
10 1 Cover Exit Hinge
11 116-1939-00 1 Exit Frame ASM
11-1 1 Guide Exit Upper
11-2 1 Roller Exit Drive
11-2-1 1 Roller Exit Drive Idle
11-3 1 Bearing Large DP
11-4 1 Ground Exit
11-5 1 Bearing Large DP
11-6 1 Gear Duplex
11-7 P/O Hardware Kit 1 C-Ring
11-8 3 Gear-Dup Idle
11-9 P/O Hardware Kit 3 CS Ring
11-10 1 Brush Antistatic
11-11 1 Holder Ground Ball
11-12 1 Guide Exit Lower
11-13 4Roller FD F
11-14 4Roller FD R
11-15 4Holder Exit
11-16 4 Spring ETC Exit Lower Idle
11-17 1 Roller Exit Idle
11-18 2 Roller Exit F_up
11-19 1 Ground Exit Plate
11-20 2 Unit-Terminal:L
11-20-1 1 Spring ETC-HV Small
11-20-2 1 Shaft HV Large
11-21 3 Spring-ETC Clutch
11-22 1 Sheet-Exit Upper
11-S8 4 Screw-Taptite
12 1 Label(P)-Exit
13 1 Guide-Exit Rear
S8 P/O Screw Kit 12 Screw-Taptite
S14 P/O Screw Kit 2 Screw-Taptite
S19 P/O Screw Kit 4 Screw-Taptite
No. Part number Qty Part Name and (part description)
