Xerox Phaser 6100 Service Manual

Parts List
9-18
11 1Gear Idle Z51
12 3Gear Idle Z53
13 1 Gear ITB (Transfer Belt) Drive 1_Z90
14 1 Gear ITB Drive 2_Z30
15 1 Gear OPC Drive 1_Z120
16 1 Gear OPC RDCN_Z120/Z60
17 1 Gear RDCN Z110/Z37
18 1 Gear RDCN Z120/Z60
19 1 Gear Swing Drive
20 1 Gear T2 Drive Z_25
21 1 Shaft Feed Drive
22 1 Shaft Fuser Drive
23 1 Shaft ITB (Transfer Belt) Drive
24 1 Shaft OPC (Imaging Unit) Drive
25 1 Shaft T2 Cam
26 1 Shaft T2 Drive
27 1 Gear Exit/ U,ID
28 1 Bracket Main Front
29 1 Bracket Main Rear
30 1 Link Solenoid
31 1 Hub Clutch
32 1 Clutch
33 3 Washer Plain
34 3 Washer Plain
35 3 Washer Plain
36 P/O Hardware Kit 1 C-Ring
37 1E-Ring
38 2ICT-PIN ADF
S11 P/O Screw Kit 6 Screw-Taptite
S17 P/O Hardware Kit 4 Screw-Taptite
No. Part number Qty Part Name and (part description)

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
