Xerox Phaser 6100 Service Manual

Parts List
9-24
1-3 1 Motor Step
1-4 1 Pick-up Solenoid
1-5 1 Gear P/UP DRV SCF
1-6 1 Gear idler Option
1-7 1 Gear idle Z30
1-8 1Gear Idle SCF
1-9 1 Bracket Gear
S9 5 Screw_Taptite
2 1 Hou-Guide Lower SCF
2-1 1 Guide Lower Rail
2-2 2 Spring CS
2-3 2 Bushing Idle Roll-SCF-16
2-4 1 Holder Idle Roll-16
2-5 1 Cover Guide Lower
2-6 1 Guide Lower
2-7 1 Roller Idle
2-8 1 Label(P) Jam
S5 4 Screw-Taptite
3 1 HOU-Guide Upper SCF
3-1 1E-ring
3-2 1 Spring Pickup
3-3 1Gear-Pickup
3-4 1 Gear Feed
3-5 1 Actuator Empty
3-6 1 Shaft Pickup
3-7 1 Guide Upper
3-8 4 Bearing Shaft
3-9 1 Bushing P/U MPT
3-10 2 Rubber Pickup
3-11 1 Roller Feed
3-12 1 Board Sub SCF Cover Sensor
3-13 1 Board Sub SCF P_Empty Sensor
4 2 Foot ML80
5 1Cam Catch
6 1 Plate Ground (A)
7 1 Plate Locker (L)
8 1 Plate Locker (R)
9 9Base Deco
10 4 Unit Terminal TR L
11 1Cover Top
12 1 Door Side
13 1Frame Base
14 1 Cover Sensor
No. Part number Qty Part Name and (part description)

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
