Xerox Phaser 6100 Service Manual

Parts List
Service Manual 9-33
Rear Frame Assembly 9.15
No. Part number Qty Part Name and (part description)
0 1 Frame Rear
1 P/O Hardware Kit 7 Ring CS
2 116-1942-00 1 CBF Harness HVPS Charge
3 116-1943-00 1 CBF Harness HVPS T1
4 116-1944-00 1 CBF Harness HVPS T2
5 1 Feed Unit
6 1 Plate Switch Duplex
7 1 Plate Guide T2 Rear
8 1 Ground Main Transfer Belt Drive
9 1 Ground Laser DEVE Drive
10 1 Ground HVPS Laser Lower
11 1 Ground Exit Drive
12 1 Gear RDCN Feed Outer
13 1Gear T2 Idle Z27
14 1 Gear T2 RDCN Z32/Z23
15 1 Lever Transfer Unit Lock Rear
16 1 Bracket Laser R
17 1 Bracket Guide HVPS F
18 1 Bracket Lock Transfer Belt
19 1 Bracket Exit Hinge R
20 1 Plate Fuser
21 1 Plate Lock Transfer Belt
22 1 Plate OPC HV
23 1 Plate T1
24 1 Plate T2
25 1 Ground HVPS
26 1 Ground Main
27 1 Frame Rear
28 1Cover T1 HV
29 1Cover T2 HV
30 1 Guide Lock Imaging Unit
31 1 Link Lock Imaging Unit
32 1 Lock Transfer Belt
33 116-1884-00 1 Holder Guide Exit
34 116-1885-00 2 Terminals
35 116-1886-00 1 Harness 100M Ground
36 116-1887-00 1 Cover Open Sensor ASM
S5 P/O Screw Kit 1 Screw-Taptite
S6 P/O Screw Kit 1 Screw-Taptite
S8 P/O Screw Kit 1 Screw-Taptite
S9 P/O Screw Kit 1 Screw-Taptite

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
