Xerox Phaser 6100 Service Manual

Parts List
Service Manual 9-35
Base Frame Assembly 9.16
No. Part number Qty Part Name and (part description)
0 116-1925-00 1 Base Frame
1 116-1889-00 1 MPT Pickup ASM
2 116-1890-00 1 Tray 1 Pickup ASM
3 116-1891-00 1 Harness SCF
4 116-1926-00 1 Assembly, AC Switch
5 1 Guide Rail
6 2 Foot ML80
7 1 Ground Tray 2 (SCF)
8 2 Screw Cover Locking Cap
9 1 Cover M Base Bar
10 1Cam Catch
11 1Gear-Pickup
12 1 Bracket Base Bar
13 1 Channel Frame Base
14 1 Bracket DEVE Hinge F
15 1 Bracket DEVE Hinge R
16 1 Bracket Power
17 1 Sheet Guide Paper
18 1Frame Base
19 1 Guide Tray 2 (SCF) Paper
20 1 Paper Guide
21 116-1959-00 1 Bearing
22 116-1892-00 1 Solenoid Pickup
23 116-1893-00 1 Temp Sensor
24 1 Washer Plain
25 1 Laser Harness Ground
26 1 Washer
S7 P/O Screw Kit 4 Screw-Taptite
S8 P/O Screw Kit 15 Screw-Taptite
S14 P/O Screw Kit 12 Screw-Taptite

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
