Xerox Phaser 6100 Service Manual

Parts List
Service Manual 9-37
MPT Assembly 9.17
No. Part number Qty Part Name and (part description)
0 116-1889-00 1 MPT Pickup ASM
1 P/O Hardware Kit 2 E Ring
2 116-1894-00 1 MPT Solenoid
3 1 Spring Cam MPT
4 1 Spring Pickup MPT
5 1Spring MPT
6 1 Bracket Solenoid
7 1Holer Cam MPT
8 1 Roller Cam MPT
9 116-1895-00 1 Actuator, MPT Empty
10 1 MPT Adjuster
11 1 MPT Cam Pickup
12 1MPT Frame
13 1MPT Holder Pad
14 1 MPT Holder Sensor
15 116-1945-00 1 PMO-Housing Pickup MPT
16 116-1946-00 1 PMO-Lift Plate, MPT
17 2 MPT Idle Pickup
18 116-1947-00 2 Bushing
19 116-1948-00 1 Pick Roller, MPT
20 1 Pad MPT (PLUS)
21 1 Pad Lift Up MPT
22 116-1896-00 1 MPT Empty Sensor
23 1Gear P/U MPT
24 1 Washer Plain
S5 P/O Screw Kit 2 Screw-Taptite
S9 P/O Screw Kit 1 Screw-Taptite

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
