Xerox Phaser 6100 Service Manual

Parts List
9-40
2 1 Holder Pinch C5
2-1 1 Holder Pinch C5
2-2 1 Roller Feed L
2-3 1 Feed Idler Shaft
3 1 Holder Pinch M
3-1 1 Holder Pinch M
3-2 1 Roller Feed L
3-3 1 Holder Feed
3-4 1 Roller Feed S
3-5 2 Feed Idler Shaft
4 1 Frame Feed
5 P/O Hardware Kit 4 E Ring
6 1 Bushing Feed Mid
7 1 Bracket Feed Mid
8 6 Washer Plain
9 116-1890-00 1 Roller Feed Mid
10 1 Shaft Feed Mid
11 3 Bushing Pickup MPT
12 1 Ground Pickup Plate
13 116-1900-00 1 Roller Feed
14 1 Shaft Feed
15 1 Gear MPT/DUP Drive
16 1 Pulley Feed L
17 1 Gelt Timing Gear
18 1 Gear Feed
19 1 Pulley Feed S
20 1 Bracket Feed
21 1 Pulley Idle
22 P/O Hardware Kit 1 Ring CS
23 1 Spring Feed MID
24 1 Spring Feed MID A
25 1 Spring Feed MPT
S8 P/O Screw Kit 5 Screw-Taptite
No. Part number Qty Part Name and (part description)

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
