Xerox Phaser 6100 Service Manual

Parts List
Service Manual 9-43
Transfer Belt Cam Assembly 9.21
No. Part number Qty Part Name and (part description)
0 116-1873-00 1 ITB Cam ASM (Transfer Belt Cam)
1 1 Transfer Belt Cam Lower
2 116-1904-00 1 PTL SensorUpper Erase Lamp (PTL)
3 116-1905-00 1 PTL Path
4 1 Shaft Transfer Belt Cleaning Cam
5 1 Transfer Belt Cleaning Cam
6 1 Bushing D6/L4
7 P/O Hardware Kit 1 E Ring
8 1 Transfer Belt Cam Upper
9 1 Harness Set Drawer
10 1 Cover Cam Shaft
11 1 Guide Erase Lamp Spring
12 P/O Hardware Kit 1 Erase Lamp Spring
13 P/O Hardware Kit 1 Ring CS
14 116-1955-00 1 Temp Sensor
S9 P/O Screw Kit 5 Screw-Taptite
S18 P/O Screw Kit 2 Screw-Special

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
