Disassembly
6-30
5. Disconnect the harness from the DEVE Motor.
6. Remove 4 harnesses connected to the DEVE drive board, then remove the DEVE drive assembly.
7. Remove 5 screws (3*10 silver) from the DEVE drive assembly.
Screw
Screw
Screw
Screw
