101
RS6000 Configuration and
Update
Introduction
This chapter describes:
• Configuring the RS6000
• Debugging logger
• Upgrading Firmware.
Configuring the RS6000
Introduction
The RS6000 is provided with a default software configuration set in the factory. This software configuration can be
optimized by the customer to meet their specific operational requirements. Therefore, before using the RS6000, it
is essential to properly configure the RS6000 to harness its extensive capabilities and gain maximum efficiency.
Configure the RS6000 by scanning special configuration bar codes or via the 123Scan
2
application. When the
RS6000 is connected to a Zebra mobile computer, some of the RS6000 configuration parameters can be
automatically overwritten by an EMDK application or DataWedge.
DataWedge
DataWedge is an application available on Zebra mobile computers. DataWedge is used to configure scanner
settings and process scanned data before sending to an application.
DataWedge is based on profiles. A profile contains information on how DataWedge should behave with different
applications. Using profiles, each application can have a specific DataWedge configuration. For example, each
user application can have a profile which outputs scanned data in the required format when that application comes
to the foreground. DataWedge can be configured to process the same set of captured data differently based on the
requirements of each application.
Once connected to a Zebra mobile computer, DataWedge settings override some of the RS6000 parameters
previously set via configuration bar codes or 123Scan
2
. These settings only apply while the RS6000 is connected
to the Zebra mobile computer, and do not persist once the RS6000 has been disconnected and reset.
For more information on DataWedge, refer to WT6000 Integrator Guide, p/n MN-002699-xx.
