UCC Coupon Extended Code

Parameter # 85 (SSI # 55h)

Enable this parameter to decode UPC-A bar codes starting with digit ‘5’, EAN-13 bar codes starting with digit ‘99’,

and UPC-A/GS1-128 Coupon Codes. UPCA, EAN-13, and GS1-128 must be enabled to scan all types of

Coupon Codes.

Enable UCC Coupon Extended Code

(1)

*Disable UCC Coupon Extended Code

(0)

NOTE: See UPC/EAN/JAN Supplemental Redundancy on page 154 to control autodiscrimination of the

GS1-128 (right half) of a coupon code.
