Bluetooth Communications

Radio Output Power

Parameter # 1324

RS6000 uses a configurable radio which can be configured to operate in:

• Low power mode as a Class 2 device

• High power mode as Class 1 device.

Increase the radio output power to increase range. Scan a bar code to select the desired power mode.

Class 1 (High Power)

*Class 2 (Low Power)
